NC Series

Solid state relay solutions grouped by load voltage for quick engineering selection.

10 Models Industrial Grade • SSR

SSR Engineering Summary

Control Voltage Groups: – 4-32VDC– 80-280VAC

Load Voltage Groups: – 24-280VAC

Current Range: 10A – 75A

NC Series Selection Check

Narrow the range by load voltage and current, then confirm control voltage, switching type, and document version.

10 models

Load condition Confirm AC / DC, single-phase / three-phase, load voltage, and maximum load current.

Control signal Match control voltage, control type, and zero-cross, random, or phase-control operation.

Thermal & accessories Review heatsink, fan, and safety cover needs by current, ambient temperature, and mounting style.

Document check Download the datasheet or send application details for KYOTTO model confirmation.

View Documents Confirm With KYOTTO Back to SSR Selection

The series page defines the model range. Before purchasing, review thermal design, accessories, document version, and application conditions.

Model selector Use load voltage, control voltage, current, and switching type to narrow the model list. Open Selector

Heatsink review Select heatsinks by SSR current, ambient temperature, and cabinet space. View Heatsinks

Accessory check Confirm safety covers, DIN rail clips, and cooling fans before ordering. View Accessories

Part Number	Phase	Function	Control Type	Control Voltage	Load Type	Load Voltage	Load Current	Switching	Docs
Normal Close 10 Models
Control Type — AC 4
NC20C10AA	Single Phase	Standard	AC	80-280VAC	AC	24-280VAC	10A	Normal Close	Data
NC20C15AA	Single Phase	Standard	AC	80-280VAC	AC	24-280VAC	15A	Normal Close	Data
NC20C25AA	Single Phase	Standard	AC	80-280VAC	AC	24-280VAC	25A	Normal Close	Data
NC20C40AA	Single Phase	Standard	AC	80-280VAC	AC	24-280VAC	40A	Normal Close	Data
Control Type — DC 6
NC20C10DA	Single Phase	Standard	DC	4-32VDC	AC	24-280VAC	10A	Normal Close	Data
NC20C15DA	Single Phase	Standard	DC	4-32VDC	AC	24-280VAC	15A	Normal Close	Data
NC20C25DA	Single Phase	Standard	DC	4-32VDC	AC	24-280VAC	25A	Normal Close	Data
NC20C40DA	Single Phase	Standard	DC	4-32VDC	AC	24-280VAC	40A	Normal Close	Data
NC20C50DA	Single Phase	Standard	DC	4-32VDC	AC	24-280VAC	50A	Normal Close	Data
NC20C75DA	Single Phase	Standard	DC	4-32VDC	AC	24-280VAC	75A	Normal Close	Data
